型號變化 |
|
|
XLR type (Supplied with a battery unit and XLR-3-12C
type connector) |
ECM-77B |
|
|
Pigtail type (Supplied without a connector ) |
ECM-77BPT |
|
|
SMC type (Supplied with a Sony 4-pin connector) |
ECM-77BC |
|
|
BMP type (Supplied with a 3.5 mm diameter, 3-pole mini
plug.) |
ECM-77BMP |
|
一般 |
|
|
重量 |
XLR type: 122公克
Pigtail type: 26公克
SMC type: 23公克
BMP type: 17公克
Microphone head only: 1.5公克 |
|
|
尺寸 (W x H x D) |
Microphone head:
直徑5.6
x 12.5 mm
Power unit (XLR type only):
直徑20.0
x 133 mm |
|
|
電源需求 |
XLR type: DC 1.5 V (ECM-88B used with the supplied DC-78
battery unit)
Pigtail/SMC/BMP type: DC 1.1 to 10.0 V |
|
|
Capsule type |
Electret Condenser |
|
|
頻率響應 |
40 Hz to 20 kHz |
|
|
方向性 |
全方位-定向 |
|
|
感度 |
XLR type: -52.0 dB ±2 dB Pigtail/SMC/BMP type: -39.0 dB
(11.2 mV) |
|
|
在1kHz的輸出阻抗 |
XLR type: 150 Ω
±20%
(balanced) Pigtail/SMC/BMP type: 2.5 kΩ
±30%
(unbalanced) |
|
|
動態範圍 |
90 dB or more |
|
|
雜訊比 (A-weighted, 1kHz, 1Pa.) |
64 dB or more |
|
|
Inherent noise (0 dB SPL = 2E-5 Pa.) |
30 dB SPL or less |
|
|
Wind noise - with windscreen, at 2 m/s (0 dB SPL = 2E-5
Pa.) |
40 dB SPL or less |
|
|
Induction noise from external magnetic field (dB SPL/1E-7
T, 0 dB SPL = 2E-5 Pa) |
5 dB SPL or less |
|
|
最大輸入聲壓級(0
dB SPL = 2E-5 Pa.) |
120 dB SPL |
|
|
電源供應 – XLR型 |
Battery: IECR6 or LR6 Battery life (LR6): Approx. 6000 h
External power: DC 12 to 48 V |
|
|
Current drain |
XLR type (internal battery): 0.3 mA or less XLR type
(external power): 2mA or less Pigtail/SMC/BMP type: 0.4
mA or less |
|
|
電纜長度 |
XLR type: 3.0 m (9.8 feet) Pigtail type: 3.0 m (9.8
feet) SMC/BMP type: 1.2 m (3.9 feet) |
