· 525i 29.97
· 625i 25
· 720P 23.98, 25, 29.97, 50, 59.94, 60 (Note: 720p 23.98 (24), 720p 25 and 720p 29.97 require a valid camera source and the use of the Record Type>VFR selection)
· 1080i 25, 29.97, 30
· 1080PsF 23.98, 24, 25*, 29.97* (Note: 25 and 29.97 require a valid camera source and the use of the Record Type>PsF selection)
· 1080p 23.98, 24, 25, 29.97
· Apple ProRes 422
· Apple ProRes 422 (HQ)
· Apple ProRes 422 (LT)
· Apple ProRes 422 (Proxy)
· Avid DNxHD 220x
· Avid DNxHD 145
· Avid DNxHD 36
(Note: Avid DNxHD is only supported for 1080p/PsF sources)
· SD/HD SDI, SMPTE-259/292/296, 10-bit
· Single Link 4:2:2 (1 x BNC)
· HDMI v1.3
· 2-channel or 8-channel user selectable
· 8-channel, 24-bit SMPTE-259 SDI embedded audio, 48kHz sample rate, Synchronous
· 2-channel, 24-bit HDMI embedded audio, 48kHz sample rate, Synchronous
· 2-channel, 24-bit A/D analog audio, 48kHz sample rate, balanced (2 x XLR)
· Input level: Line, Mic, Mic+phantom 48Vdc
· +24dbu Full Scale Digital
· +/- 0.2db 20 to 20kHz Frequency Response
· 8-channel, 24-bit HDMI embedded audio, 48kHz sample rate, Synchronous
· SDI RP188/SMPTE 12M via SDI BNC
· HDMI (when used with compatible cameras)
· LTC input (1x BNC)
· 10/100/1000 Ethernet (RJ-45)
· Embedded web server for remote control
· LANC Loop (2 LANC Connectors) (Note: requires a LANC enabled camera)
寬度: 11.06公分 深度: 4.62公分 高度: 14.998公分
100 ~ 240V AC 50/60Hz(adapter), 12 ~ 18V DC 4-pin XLR (chassis) 1.5A max 15W
