·         525i 29.97

·         625i 25

·         720P 23.98, 25, 29.97, 50, 59.94, 60 (Note: 720p 23.98 (24), 720p 25   and 720p 29.97 require a valid camera source and the use of the Record Type>VFR selection)

·         1080i 25, 29.97, 30

·         1080PsF 23.98, 24, 25, 29.97, 30

·         1080PsF 23.98, 24, 25*, 29.97* (Note: 25 and 29.97 require a valid camera source and the use of the Record Type>PsF selection)

·         1080p 23.98, 24, 25, 29.97

·         Apple ProRes 422

·         Apple ProRes 422 (HQ)

·         Apple ProRes 422 (LT)

·         Apple ProRes 422 (Proxy)

·         AJA Ki Stor modules - 1 slot

·         ExpressCard/34 - 2 slots (Only Slot 1 active, See www.aja.com for supported media)

·         SD/HD SDI, SMPTE-259/292/296, 10-bit

·         Single Link 4:2:2 (1 x BNC)

·         HDMI v1.1

·         SD/HD Component (3 x BNC)

·         SMPTE/EBU N10, Betacam 525 line, Betacam 525J

·         12-bit A/D, 2x oversampling

·         +/- .25 dB to 5.5 MHz Y Frequency Response

·         +/- .25 dB to 2.5 MHz C Frequency Response

·         .5% 2T pulse response

·         <2 ns Y/C delay inequity

·         SD/HD SDI, SMPTE-259/292/296, 10-bit

·         Single Link 4:2:2 (1 x BNC)

·         HDMI v1.1

Note: HDMI requires 1080i, 720p or 1080p to be active; HDMI does not provide support for PsF

·         Composite (1xBNC)

·         NTSC, NTSCJ, PAL

·         12-bit D/A, 8x oversampling

·         +/- .2 dB to 5.0 MHz Y Frequency Response

·         +/- .2 dB to 1 MHz C Frequency Response

·         .5% 2T pulse response

·         <1% Diff Phase

·         <1% Diff Gain
Note: Composite output requires that the Component Analog output be set to SD; composite output does not support HD

·         Component (3 x BNC)

·         HD: YPbPr, RGB

·         SD: YPbPr, RGB (component mode)

·         SMPTE/EBU N10, Betacam 525 line, Betacam 525J, RGB

·         12-bit D/A, 8x oversampling

·         +/- .2 dB to 5.5 MHz Y Frequency Response

·         +/- .2 dB to 2.5 MHz C Frequency Response

·         .5% 2T pulse response

·         <1 ns Y/C delay inequity

·         2-channel or 8-channel user selectable

·         8-channel, 24-bit SMPTE-259 SDI embedded audio, 48kHz sample rate, Synchronous

·         2-channel, 24-bit HDMI embedded audio, 48kHz sample rate, Synchronous

·         2-channel, 24-bit A/D analog audio, 48kHz sample rate, balanced (2 x XLR)

·         Input level: Line, Mic, Mic+phantom 48Vdc

·         +24dbu Full Scale Digital

·         +/- 0.2db 20 to 20kHz Frequency Response

·        2-channel unbalanced (2 x RCA)

·         8-channel, 24-bit SMPTE-259 SDI embedded audio, 48kHz sample rate, Synchronous

·         2-channel, 24-bit HDMI embedded audio, 48kHz sample rate, Synchronous

·         2-channel, 24-bit D/A analog audio, 48kHz sample rate, balanced (2 x XLR)

·         +24dbu Full Scale Digital (0dbFS)

·         +/- 0.2db 20 to 20kHz Frequency Response

·         2-channel unbalanced (2 x RCA)

·        Stereo unbalanced headphone (1 x 3.5mm mini jack)

·         Hardware 10-bit

·         Anamorphic: full-screen

·         Pillar box 4:3: results in a 4:3 image in center of screen with black sidebars

·         Zoom 14:9: results in a 4:3 image zoomed slightly to fill a 14:9 image with black side bars

·         Zoom Letterbox: results in image zoomed to fill full screen

·         Zoom Wide: results in a combination of zoom and horizontal stretch to fill a 16:9 screen; this setting can introduce a small aspect ratio change

·         Hardware 10-bit

·         Anamorphic: full-screen

·         Letterbox: image is reduced with black top and bottom added to image area with the aspect ratio preserved

·         Crop: image is cropped to fit new screen size

·         Hardware 10-bit

·         1080i to 720P

·         720P to 1080i

·         SDI RP188/SMPTE 12M via SDI BNC

·         LTC input (1 x BNC)

·         LTC output (1x BNC) (Note: active during playback not during record or EE)

·         10/100/1000 Ethernet (RJ-45)

·         802.11g Wireless

·         Embedded web server for remote control

·         LANC Loop (2 LANC Connectors) (Note: requires a LANC enabled camera)

·         Lens Tap (Note: Not activated).

·         IEEE-1394a/FireWire400 for control and timecode data

·         RS-422, Sony 9-pin protocol.

·         9-pin D-connector pinout is as follows:

寬度: 22.86公分
深度: 15.56公分
高度: 8.25公分

100 ~ 240V AC 50/60Hz(adapter),
12 ~ 18V DC 4-pin XLR (chassis)
3.3A max
30W 典型
